Overview
The AZ5725-01F is a single-channel bidirectional ESD protection diode in a DFN1006-2L package, primarily used for electrostatic discharge (ESD) protection of power lines, control signal lines, and low-speed data interfaces.
For engineers and purchasing personnel looking for alternatives to the AZ5725-01F, in addition to package compatibility, key parameters such as operating voltage, ESD protection capability, leakage current, and clamping voltage are crucial.
The Semiware SE10F10B5.0A is a DFN1006-2L bidirectional ESD protection device with a similar application focus to the AZ5725-01F, and can be considered as an alternative in electronic equipment protection solutions.
AZ5725-01F vs SE10F10B5.0A Parameter Comparison
| Parameter | AZ5725-01F | SE10F10B5.0A |
| Device Type | ESD Protection Diode | ESD Protection Diode |
| Channel | 1-Line | 1-Line |
| Direction | Bidirectional | Bidirectional |
| Package | DFN1006-2L | DFN1006-2L |
| Working Voltage (VRWM) | 5V | 5V |
| Breakdown Voltage (VBR) | 5.8V ~ 9.0V | ≥5.6V |
| Clamping Voltage (VC) | 10V | 10V |
| ESD Protection | ±15kV (air), ±15kV (contact) | ±25kV (air), ±25kV (contact) |
| Leakage Current (IR) | ≤1μA | ≤0.1μA |
| Junction Capacitance (CJ) | 10pF | 15pF |
| Operating Temperature | -55°C to +85°C | -55°C to +125°C |
Why SE10F10B5.0A Can Replace AZ5725-01F?
- Compatible Package Design
SE10F10B5.0A adopts the same DFN1006-2L package as AZ5725-01F, helping simplify PCB redesign when evaluating replacement options.
- Enhanced ESD Protection
With IEC61000-4-2 ±25kV ESD protection capability, SE10F10B5.0A provides improved protection against electrostatic discharge events.
- Lower Leakage and Reliable Protection
The low leakage current design helps improve system efficiency while protecting sensitive semiconductor components.
- Supply Chain Flexibility
SE10F10B5.0A provides an alternative source for customers looking for second-source solutions or supply chain optimization.
SE10F10B5.0A Datasheet
SE10F10B5.0A ESD Protection Diode Typical Applications
- Cell phones and accessories
- Microprocessor-based equipment
- Consumer electronics
- Industrial control systems
- Portable instrumentation
- External interfaces
Reference Circuit
Conclusion
The Semiware SE10F10B5.0A shares similar electrical characteristics and package compatibility with the AZ5725-01F, making it an ideal alternative for engineers seeking a 5V, bidirectional ESD protection diode in a DFN1006-2L package.
Looking for a reliable alternative to the AZ5725-01F?
Contact Semiware to obtain samples, datasheets, and technical support for the SE10F10B5.0A to evaluate your ESD protection design.
