TVS Diode Array

SD36CActive

The SD36C TVS diode delivers powerful transient voltage suppression in an ultra-small SOD-323 package,making it the ideal solution for space-constrained and high-performance electronics.With up to 350W peak pulse power,ultra-fast response time,and low clamping voltage,this device ensures your sensitive components stay safe from ESD strikes,surges,and transients.Ideal for applications such as USB ports,RJ45 Ethernet connectors, HDMI lines, and other sensitive signal interfaces.

Datasheet Inquire Now

Electrical Parameters

Part Number SD36C

Package SOD-323

Vrwm [Max] (V) 36

Vbr [Min] (V)40

Vc@Ipp [Max] (V)75

Ipp [Max] (A)4.5

Vesd [Contact] (KV)±30

Vesd [Air] (KV)±30

IR [max] (uA)0.2

Cj [max] (pF)18

TJ (°C)-55～+150

Status Active

Product Features

Low Clamping Voltage Low Leakage Current 350W Peak Pulse Power Protects One I/O Line IEC61000-4-4 (EFT) 40A ROHS Compliant
